Main Sales Markets: North America,Central/South America,Western Europe,Eastern Europe,Australasia,Eastern Europe,Australasia,Asia,Middle East,Africa
Sample Provided: no
The operating principle of Pnuematic Rotary Valve is: The media from upper cabinet fall down to the space between blades by gravity and discharged within the rotary of blades. So the pneumatic rotary valve normally used for discharge media within continuously and quantitative, also used for pellet/power transportation; For the pressure output system and subpressure output system, the pneumatic rotary valve can ensure the media transporated with continuously and quantitative. All control elements operated by compress air to avoid the explosion in processing. The valve widely used in food industry, biologicals industry, milk industry and sugar industry.
Specification: 2.0”~12.0”
Operating Pressure:：-0.1Mpa~+0.5Mpa
Compress Air Pressure: 0.4~0.8Mpa
Actuator: 0-180° （standard）
0-90°, Pneumatic rotary motor(Option)
Operating Temperature:-20℃~+150℃
Body Material：304/316L(Touch media parts）
304（Not touch media parts）
Seal Material: Fluorinated rubber（White colour, meet FDA 21.CRF177.266, standard）
Silicon rubber, EPDM(Option)
Surface: Ra<0.4 (Touch media parts)）
Ra<0.8（Not touch media parts）
Sealing Mode: Unsealed(Standard)
Sealed(Option)
Sterilization Method:SIP
Anti-explosion grade: ATEX Ⅱ2 GD T4
Connection Standard: DIN11850 series 2、ASME-BPE、ISO1127 series 1
Connection Mode: Quick Joint, Flange
Spare Parts: Pneumatic control
valve, Feedback indicator
